Unparalleled Sound Clarity and Performance

When it comes to creating an immersive audio experience, the Bose Professional DesignMax DM6SE 2-way surface mount loudspeaker stands out as a pinnacle of acoustic engineering. This loudspeaker is not just a technological marvel; it's a testament to the perfect blend of form and function. Designed to deliver rich lows and clear, intelligible highs, the DesignMax DM6SE is the epitome of Bose's commitment to professional-grade sound quality.

Sophisticated Design for Any Setting

The DesignMax DM6SE boasts an elegant design that seamlessly integrates into any commercial space. Its minimum-bezel grille, available in black or white, is paintable to match any decor, ensuring that the loudspeaker complements your space rather than intruding upon it. The removable logos allow for a discreet presence, maintaining the aesthetic integrity of your venue.

Exceptional Audio Quality

At the heart of the DesignMax DM6SE lies a coaxial two-way driver system, combining a 6.5-inch woofer and a 1.25-inch neodymium dome tweeter. This configuration ensures a consistent audio experience with rich bass and crystal-clear highs. Whether it's for background music or the centerpiece of a sound system, the DM6SE delivers:

• Frequency Range: 59 Hz – 20 kHz
• Sensitivity: 90 dB SPL/1 W at 1 m
• Maximum SPL at 1 m: 111 dB

Broad Coverage for Any Space

The DesignMax DM6SE offers a generous 125° conical horizontal coverage, ensuring that sound is distributed evenly across the listening area. This feature makes the DM6SE particularly suitable for venues where audio clarity and coverage are essential, such as performing arts venues, places of worship, and conference centers.

Power Handling for Demanding Applications

With a continuous power handling capacity of 125 W and peak power handling of 500 W, the DesignMax DM6SE is more than capable of delivering dynamic and impactful sound. The inclusion of transformer taps for both 100V and 70V systems allows for versatility in installation and ensures compatibility with various audio setups.

Weather-Resistant for Outdoor Use

The IP55 outdoor rating of the DesignMax DM6SE ensures it is ready to withstand the elements. The highly UV fade-resistant engineered plastics and the standard aluminum grille offer protection against sun, rain, and dust, making this loudspeaker an excellent choice for outdoor areas like patios and terraces in hospitality venues.

Easy Installation with QuickHold Mounting

Installation is a breeze with the patented QuickHold U-bracket, which provides fast and secure mounting. This feature, along with industry-standard accessories, guarantees that integrating the DesignMax DM6SE into your space is straightforward and hassle-free.

Applications Across Various Venues

The versatility of the DesignMax DM6SE makes it suitable for a wide range of applications:

• Performing arts venues
• Places of worship
• Conference centers
• Retail stores
• Restaurants and bars
• Hospitality venues

Built to Last

The DesignMax DM6SE is not only designed for exceptional performance but also for durability:

• Operating Temperature: -25 °C to 70 °C (-13 °F to 158 °F)
• Enclosure Material: Engineered plastics, highly UV fade-resistant
• Grille Material: Perforated aluminum, powder-coated finish
• Safety Agency Ratings: UL-1480A, UL Listed, NFPA70, CE compliant

No Compromise on Sound Quality

Bose's proprietary Dispersion Alignment system ensures a consistent listening experience for all audience members, no matter their location in the venue. The DesignMax DM6SE delivers pristine sound without the need for additional signal processing, although Bose Professional EQ voicing and SmartBass processing are available if desired.

Technical Specifications at a Glance

• Model: Bose Professional DesignMax DM6SE
• Type: 2-way surface mount loudspeaker
• Drivers: Coaxial 6.5-inch woofer and 1.25-inch neodymium dome tweeter
• Continuous Power Handling: 125 W
• Peak Power Handling: 500 W
• Transformer Taps: 100V and 70V options with bypass
• Environmental Protection: IP55 outdoor-rated
• Mounting: QuickHold U-bracket
• Dimensions (H×W×D): 13.4 in × 8.7 in × 9.0 in
• Net Weight: 5.9 kg per loudspeaker with grille

Your Dreamedia Home Theater Experts

At Dreamedia, we understand that choosing the right audio equipment is crucial to creating the perfect ambiance for your venue. We're here to guide you through the process, offering expert advice tailored to your specific needs. Whether you're looking to enhance the audio experience in a house of worship, elevate the atmosphere in a restaurant, or provide crystal-clear sound for a conference center, we have the expertise to bring your vision to life.

Invest in Exceptional Sound Today

The Bose Professional DesignMax DM6SE is more than just a loudspeaker; it's an investment in unparalleled sound quality and reliability. With its sophisticated design, exceptional audio performance, and easy installation, the DM6SE is the ideal choice for those who refuse to compromise on their audio experience. Contact Dreamedia today, and let us help you design the perfect sound system for your space.
